PLANK TYPE FLOORING

Plank type flooring is used for all types of industrial flooring, mezzanine floor structures, gangways, etc. Plank type flooring can cross spans of up to 2 metres.

PLANK TYPE FLOORING

Plank type flooring is used for all types of industrial flooring, mezzanine floor structures, gangways, etc. Plank type flooring can cross spans of up to 2 metres.


Plank type flooring is used for all types of industrial flooring, mezzanine floor structures, gangways, etc. The plank type flooring can cross spans of up to 2 metres, which means that the supporting beams can be placed further apart and the assembly is faster. When mounting, the plank type flooring is screwed to the underlying material. More information about loads for plank type flooring.

Profiles, Plank type flooring

Plank type flooring is manufactured in 4 different profiles and 3 different widths. We can supply plank type flooring in different lengths, up to 6000 mm

Plank type flooring consists of profiles in different widths. With different widths laid next to each other so you get the desired total width. The height of the light floor is always 48 mm.


Plank types, plank type flooring

Plank type flooring is manufactured in 4 different patterns with unique characteristics and applications.

Characteristics: This plank type has an embossed pattern offering good anti-slip protection.

Application: Wherever a closed floor is needed. Because the planks are closed, insulation can be installed in or under the planks. The 6000 mm length is held in stock.

Profiles are available in widths of 200, 250 and 300 mm.

Characteristics: In principle, it is a closed plank type flooring that is supplemented with punched oval holes, 15×69 mm, to let through light, dirt and liquids.

Application: Whenever a relatively smooth, yet pervious floor is required. Suitable when, for example, wheeled objects will be moved across the floor. The 6000 mm length is held in stock.

Profiles are available in widths of 200, 250 and 300 mm.

Characteristics: Just like LDH, a plank type with great permeability for dirt and liquids. The serrated top provides extremely good anti-slip protection.

Application: Wherever there are strict requirements for anti-slip protection. The 6000 mm length is held in stock.

Profiles are available in widths of 200, 250 and 300 mm.

Characteristics: Very good anti-slip protection, but not as great a permeability as LDS. This type has smaller openings (holes Ø 10 mm and 4 mm drain holes) and thus provides more safety from objects falling through the openings.

Application: Wherever there are strict requirements for anti-slip protection and where it is not permitted for objects to fall through the openings. The 6000 mm length is held in stock.

Profiles are available in widths of 200, 250 and 300 mm.


Accessories, plank type flooring

As accessories, there are a number of different parts that facilitate the installation as well as the use of the plank type flooring.

Kick strip LK140 is a special profile, located at all openings and all outer edges of the plank. Fastens to the plank type flooring using screws.

Outside and inside corners at 90° angles are available for kick strips.

Profile LU43 is used as reinforcement, plank edging and as a border profile in the case of longitudinal cutting of the plank.


Surface treatment

Plank type flooring is delivered as standard hot dip galvanized according to SS-EN ISO 1461. For more information, please visit our page for surface treatment.

Hot dip galvanized
